AFG Double Wall Crucible Glass Kiln

AFG Double Wall Crucible Glass Kiln

Regular price $3,214.00 USD
Regular price Sale price $3,214.00 USD
Sale Sold out
Shipping calculated at checkout.

Molten Glasswork, Melting Cullet

NOTE: The model pictured features the Orton AutoFire 4000 12-Button Controller (starting at $3,444). The price displayed on the site reflects the standard model with the AutoFire (AF4X) 3-Button Controller ($3,214).

View full details

DOUBLE WALL CRUCIBLE

PRODUCT DESCRIPTION

ABOUT

The Double Wall (DW) Crucible kiln is designed for melting and working with cullet, offering precise temperature control for efficient glassworking from melting to shaping. It reaches a maximum temperature of 2300°F to efficiently melt cullet, then cools to 1800°F for controlled glass squeezing.

For gathering, the kiln maintains a working range of 2050°F to 2100°F, ensuring optimal consistency. Between sessions, it holds at 1800°F until it's time to ramp back up to the gathering temperature.

It includes solid-state relays for precise and reliable temperature control, a kiln shelf for convenient firing, a kiln stand that provides a sturdy base for safe and reliable use, and a manual with clear instructions for easy setup and operation.

Unlike our other crucible kilns, this kiln features a double-wall design, providing enhanced insulation and energy efficiency. The additional layer of insulation improves heat retention, ensures more even heat distribution, and keeps the kiln’s exterior cooler to the touch. This design also contributes to greater durability and longevity compared to single-wall crucible kilns. The improved heat retention and even heat distribution result in more efficient firings, while the cooler exterior provides added safety during operation. The double-wall design also enhances the kiln's durability, extending its lifespan when compared to single-wall models.

NOTE: Electric Crucible Kilns are specifically designed for melting cullet and are not suitable for making glass from batch, as the caustic fumes produced can rapidly deteriorate the thermocouple and kiln brick. Coils typically last three to six months in crucible kilns and are not covered under warranty.

Looking for more crucible options? Explore our other Crucible kilns! (linked text)

Explore our other Crucible kilns!

KEY FEATURES

  • Best for: Molten glasswork

  • Cullet Melting: Specifically designed for melting cullet (not for making glass from batch), with a maximum temperature of 2300°F for efficient melting.

  • Double-Wall Insulation: Optimizes heat retention and firing efficiency.

  • Precise Temperature Control: Cools down to 1800°F for controlled glass squeezing and maintains a gathering range of 2050°F to 2100°F for consistent results.

  • Perfect for Smaller Projects: Ideal for roll-ups and smaller glass projects, providing precise and efficient heat.

  • Solid-State Relays Included: Provide long-lasting performance with precise and reliable temperature control.

  • Kiln Shelf Included: Provides a convenient surface for firing your glass pieces.

  • Sturdy Metal Stand Included: Ensures stability and easy access to your kiln, providing a solid base for safe and reliable use.

WHAT'S INCLUDED

  • Orton AutoFire 3-Button Digital Controller
  • Solid-State Relays
  • Kiln Stand
  • Instruction Manual

HELPFUL HINTS

When between sessions, hold the kiln temperature at 1,800°F, then turn back to work at the gathering temperature.

WARRANTY

Includes a 2-year limited warranty for both the kiln and controller. Learn more on the Warranties page.

BEFORE YOU PURCHASE

Before purchasing any Jen-Ken Kiln, we recommend that you give us a call at (800) 329-KILN to discuss your unique needs, studio setup, and electric requirements, ensuring you order the right kiln with confidence.

Product Specifications

PRODUCT SPECIFICATIONS

Kiln Model AF3P Double Wall Crucible
Kiln Function Molten Glasswork
Interior Dimensions 19” x 22”
Cubic Feet 2.9ft³
Top/Side Firing Side
Max Temp 2,300°F
Voltage 240V
Amperage 42A
Wattage 10,080W
Receptacle 6-50R
Breaker 50A
Circuit Wire Gauge 6
Kiln Weight 350 lbs
Shipping Weight (Average) 400 lbs
Shipping Method Motor Freight - Call for Quote
